2010 Victory Touring

2010 Victory Vision Tour - Award-Winning Luxury-Touring Model

• Provides tremendous comfort for 1 or 2 riders, easy handling, smooth ride, copious cargo space, outstanding power & performance
• Ideal for riders who frequently take long-distance trips & usually ride 2-up
• Bike has integrated audio system & is wired to accommodate iPod® , MP3 & GPS

New or Improved for 2010

• Driver seat has slot designed to accept accessory Driver Backrest
• Auxiliary power outlets (in console storage box & in rear storage compartment) are now cigarette lighter-style outlet for commonality
• Side stand has new extension that makes it easier to locate and operate; accessory Center Stand available
• “Silencer” affixed to airbox lessens intake sound level significantly
• Audio display provides higher-resolution graphics and additional information about playlists, artists, tracks, satellite radio station & more

Engineered For Touring and Comfort

• Victory Vision Tour has the lowest driver seat height in the luxury-touring class
• Front of driver seat is narrow so driver’s legs stretch directly to the ground
• Both seats have 4” of padding for long-riding comfort
• Heated seats with separate controls for driver & passenger seats; improved heating control for consistent temperature
• Passenger has plush backrest, floorboard-style footrests & sits higher than driver for a good view
• Passenger Armrests and Passenger Footrest Risers available as accessories
• Long, integrated floorboards let the driver vary leg & foot positions to stay fresh & comfortable
• Heated grips and cruise control are standard
• Electronically adjustable windscreen lets driver manage airflow
• With windscreen raised, wind & rain are deflected over riders, buffeting is minimized
• Manually adjustable side wind deflectors manage airflow to seating area
• Instrumentation is positioned for easy, heads-up viewing

Cargo Capacity For Touring Riders

• Total volume of rear storage compartment & dual side storage areas is 29.2 gallons
• Spacious, lockable rear storage compartment has room enough for two full-face helmets
• Dual side storage units are spacious, weatherproof, lockable
• Console storage compartment with electronics connection is conveniently in front of the rider

Style & Innovation

• Custom-style billet “Anvil” wheels
• HID (High Intensity Discharge) Driving Beam is standard
• Reverse available as an accessory
• Headlight remains off with key in “ON” position but engine not running; the light turns on when the engine is started
• Controls are conveniently mounted by handgrips or on console in front of driver
• Lighting includes excellent headlight light pattern and distinctive V-shaped taillight

Smooth, Powerful Victory Freedom 106/6 Stage 1 V-Twin

• 106ci/1731cc engine with 6-speed transmission with Overdrive
• 92 horsepower & 109 ft-lbs. torque
• Engine is calibrated specifically for peak performance in the Victory Visions
• Closed Loop Fuel Injection
• 6-gallon fuel capacity and electronic fuel gauge

Easy-Adjust Rear Suspension

• Rear suspension features air shock combined with coil spring
• Rider uses easy-access air valve on side of bike to adjust air pressure in shock to suit the cargo/passenger load
• 4.7” (120mm) of rear suspension travel

Linked Brake System

• Rear brake is hydraulically linked to the front brakes
• On moderate to heavy braking with rear brake pedal, front braking is activated hydraulically to enhance overall braking
• Light braking with the rear brake pedal activates only the rear brake
• Front braking: Dual 300mm floating rotors with 3 pistons per caliper
• Rear braking: Single 300mm rotor with 2-piston caliper

Victory Vision Tour Colours For 2010

• Solid Pearl White
• Two-Tone Ocean Blue & Sandstone Metallic

Pure Victory Gear Accessories

Accessories available from Pure Victory Gear include:

• Stage 1 Performance Exhaust system and chrome fluted exhaust tips
• Accommodates various electronics, including new Garmin® zumo®660 GPS
• New Passenger Armrest are adjustable & include a cup holder
• Additional storage options include Ultimate Solo Touring Bag & Trunk Rack
• Pure Victory Gear offers over 77 Victory Vision model-family accessories

New 2010 Victory Vision Tour ABS

New: Anti-Lock Brake System (ABS)

• Automotive-style ABS optimizes braking effectiveness in all riding conditions
• Sensors on each wheel monitor wheel speed during braking
• If system senses slippage or wheel lock, it engages and delivers braking that slows the wheel without locking it
• Rider maintains brake pressure, ABS manages braking for surest stopping
• ABS is most commonly engaged in emergency stops and on slippery road surfaces
• ABS control module is located near side storage compartment
• Bike’s rear brake is hydraulically linked to the front brakes
• On moderate to heavy braking with rear brake pedal, front braking is activated hydraulically to enhance overall braking
• Front braking: Dual 300mm floating rotors with 3 pistons per caliper
• Rear brake: Single 300mm rotor with 2-piston caliper

Award-Winning Luxury-Touring Model

• Provides tremendous comfort for 1 or 2 riders, easy handling, smooth ride, copious cargo space, outstanding power & performance
• Ideal for riders who frequently take long-distance trips & usually ride 2-up
• Bike has integrated audio system & is wired to accommodate iPod® , MP3 & GPS

New or Improved For Model Yeay 2010 (along with ABS)

• Driver seat has slot designed to accept accessory Driver Backrest
• Auxiliary power outlets (in console storage box & in rear storage compartment) are now cigarette lighter-style outlet for commonality
• Side stand has new extension that makes it easier to locate and operate; accessory Center Stand available
• “Silencer” affixed to airbox lessens intake sound level significantly
• Audio display provides higher-resolution graphics and additional information about playlists, artists, tracks, satellite radio station & more

Engineered For Touring & Comfort

• Victory Vision Tour models have the lowest driver seat height in the luxury-touring class
• Front of driver seat is narrow so driver’s legs stretch directly to the ground
• Both seats have 4” of padding for long-riding comfort
• Heated seats with separate controls for driver & passenger seats; improved heating control for consistent temperature
• Passenger has plush backrest, floorboard-style footrests & sits higher than driver for a good view
• Passenger Armrests and Passenger Footrest Risers available as accessories
• Long, integrated floorboards let the driver vary leg & foot positions to stay fresh & comfortable
• Heated grips and cruise control are standard
• Electronically adjustable windscreen lets driver manage airflow
• With windscreen raised, wind & rain are deflected over riders, buffeting is minimized
• Manually adjustable side wind deflectors manage airflow to seating area
• Instrumentation is positioned for easy, heads-up viewing

Cargo Capacity For Touring Riders

• Total volume of rear storage compartment & dual side storage areas is 29.2 gallons
• Spacious, lockable rear storage compartment has room enough for two full-face helmets
• Dual side storage units are spacious, weatherproof, lockable
• Console storage compartment with electronics connection is conveniently in front of the rider

Style & Innovation

• Custom-style billet “Anvil” wheels
• HID (High Intensity Discharge) Driving Beam is standard
• Reverse available as an accessory
• Headlight remains off with key in “ON” position but engine not running; the light turns on when the engine is started
• Controls are conveniently mounted by handgrips or On console in front of driver
• Lighting includes excellent headlight light pattern and distinctive V-shaped taillight

Smooth, Powerful Victory Freedom 106/6 Stage 1 V-Twin

• 106ci/1731cc engine with 6-speed transmission with Overdrive
• 92 horsepower & 109 ft-lbs. torque
• Engine is calibrated specifically for peak performance in the Victory Visions
• Closed Loop Fuel Injection
• 6-gallon fuel capacity and electronic fuel gauge

Easy-Adjustable Rear Suspension

• Rear suspension features air shock combined with coil spring
• Rider uses easy-access air valve on side of bike to adjust air pressure in shock to suit the cargo/passenger load
• 4.7” (120mm) of rear suspension travel

Victory Vision Tour ABS Colours For 2010

• Solid Black
• Two-Tone Ocean Blue & Sandstone Metallic

Pure Victory Gear & Accessories

Accessories available from Pure Victory Gear include:

• Stage 1 Performance Exhaust system and chrome fluted exhaust tips
• Accommodates various electronics, including new Garmin® zumo®660 GPS
• New Passenger Armrest are adjustable & include a cup holder
• Additional storage options include Ultimate Solo Touring Bag & Trunk Rack
• Pure Victory Gear offers over 77 Victory Vision model-family accessories
