2009 Triumph Street Triple R

2009 Triumph Street Triple RTriumph Street Triple R09 Triumph Street Triple R

Following on from the phenomenally successful Street Triple, Triumph is introducing a new, higher-specification version, for 2009 – the Street Triple R.

With the Street Triple already regarded as the class-leading middleweight streetfighter, the ‘R’ version takes the standard bike and adds a whole heap of attitude. The Street Triple R is not a bike for shrinking violets…
The new Street Triple R comes brimming with race track technology. Fully-adjustable 41mm upside down forks and a topspec rear monoshock unit with piggy back reservoir deliver sublime handling, while radially-mounted four piston calipers grab the twin 308mm brake discs and ensure the Street Triple R stops as well as it goes.

At the heart of Street Triple R is the Street Triple’s highly-acclaimed fuel injected 675cc three-cylinder unit, producing 108PS at 11,700rpm, while its fully adjustable sports suspension and powerful four-piston radial brakes are derived from the award-winning Daytona 675. The new Street Triple R has been designed to rival traditional supersport machines with its superlative handling and stunning stopping power, while offering the comfort and attitude of a streetfighter. The sporty feel is completed with wide, tapered, handlebars from Magura and a 5mm taller seat height that puts the Street Triple R rider in the perfect position to attack the twisty stuff or cut its way through the urban jungle.

The result is a motorcycle that can be finely tuned for all road and track conditions, offering a plush ride tailored to the individual rider, while bearing more than a passing resemblance to its famous brother, Triumph’s mighty Speed Triple.

Completing the Street Triple R’s distinctive look is an all-new colour scheme of Matt Graphite with orange graphics. A Matt Blazing Orange option with grey graphics will also be available from early 2009. Both colour options are further enhanced by black anodised forks and a two-tone black and graphite seat.

A full range of Triumph accessories are available for the bike, including practical and stylish flyscreens and a range of performance exhaust systems developed in collaboration with Italian performance specialists Arrow Special Parts


  • Engine type - liquid-cooled, 12 valve, DoHc, in-line 3-cylinder
  • capacity - 675cc
  • Bore/Stroke - 74.0 x 52.3mm
  • fuel System - Multipoint sequential electronic fuel injection with Sai
  • final Drive - o ring chain
  • clutch - Wet, multi-plate
  • Gearbox - 6-speed, close ratio
  • frame - aluminium beam twin-spar
  • Swingarm - Braced, twin-sided, cast aluminium alloy
  • Wheels - front; cast aluminium alloy 5-spoke 17 x 3.5in
  • rear; cast aluminium alloy 5-spoke 17 x 5.5in
  • tyres - front; 120/70 Zr 17
  • rear; 180/55 Zr 17
  • Suspension - front; Kayaba 41mm upside down forks with adjustable preload, rebound and ompression damping, 120mm travel
  • rear; Kayaba monoshock with piggy back reservoir adjustable for preload, rebound and compression damping, 130mm rear wheel travel
  • Brakes - front; twin 308mm floating discs. nissin 4-piston radial calipers
  • rear; Single 220mm disc, nissin single piston caliper
  • front brake - master cylinder nissin radial master cylinder 19mm diameter
  • instrument display/functions - LCD multi-functional speedometer, trip computer, analogue tachometer, lap timer, gear position indicator and programmable gear change lights
  • length - 2030mm (79.9in)
  • Width (Handlebars) - 731mm (28.8in)
  • Height - 1250mm (49.2in)
  • Seat Height - 805mm (31.6in)
  • Wheelbase - 1390mm (54.7in)
  • rake/trail - 23.9º/92.4mm
  • Dry Weight - 167kg (367lbs)
  • fuel tank capacity - 17.4 litres (3.8 gal / 4.6 US gals)
  • Maximum power - 108pS / 107bhp / 79kW @ 11700rpm
  • Maximum torque - 69nm / 51ft.lbf @ 9100rpm
